Oil Drum Trolley
Portable Eagle Mouth Manual Oil Drum Truck Adjustable Jaw Hydraulic Drum Lifter For Chemical Factory
This manual hydraulic oil drum trolley adopts durable alloy steel eagle claw jaw, compatible with 200L steel drums and plastic barrels, load capacity 350kg / 450kg optional. Foot hydraulic lifting design, automatic locking jaw to prevent drum falling during transport.
Portable Eagle Mouth Manual Oil Drum Truck Adjustable Jaw Hydraulic Drum Lifter For Chemical Factory
Product Overview
Manual hydraulic oil drum trolley is professional handling equipment for transporting standard 200L (55 gallon) oil barrels. Equipped with adjustable eagle claw gripping structure, it can safely clamp both metal steel drums and plastic barrels without extra modification. Manual foot hydraulic pump lifts the drum 300mm off the ground for smooth transfer, no electric power required, compact lightweight body for narrow space operation. It greatly reduces labor intensity and avoids safety risks of manual barrel lifting.
Core Advantages
- Alloy Steel Adjustable Eagle Claw Jaw High hardness cast steel gripper with spring auto-locking design, strong clamping force, not easy to slip off during moving. Jaw height adjustable to fit different barrel rim sizes, protects barrel edge from deformation and scratch, suitable for steel & plastic dual-purpose barrels.
- Anti-leak Foot Hydraulic Lifting System Integrated hydraulic cylinder with multi-layer oil seals, no oil leakage or pressure loss. Foot pedal lifting + hand slow lowering control, buffer descent to avoid sudden drum drop. Built-in overload protection valve extends hydraulic service life. Max lifting height 300mm for smooth cross-road transfer.
- Reinforced Heavy-duty Frame Main beam made of thick Q345 carbon steel, integral welding and electrostatic anti-rust spray coating, high tensile strength, long service life under daily heavy load. U-shaped arc barrel support fits barrel surface tightly to prevent shaking during transit.
- Flexible Safe Wheel Configuration Multiple wheel options: Nylon silent wheel, PU wheel, solid rubber wheel, inflatable wheel. Front swivel auxiliary caster for flexible turning in narrow workshops; optional parking brake locks trolley to prevent sliding during loading/unloading.
- Wide Compatibility & Easy Operation Single-person operation, no extra tools needed, fast clamp and release barrels. Perfect for 200L closed steel drum, open steel barrel, plastic chemical barrel, fiber drum.
- Export Customization Service Complete CE certification for global export trade. Customizable load capacity, wheel type, frame color, OEM logo printing supported.
Technical Specification Table
Item | Standard Parameter |
|---|---|
Rated Load Capacity | 350kg / 450kg |
Max Lifting Height | 300mm |
Applicable Drum | 200L / 55 Gallon Steel & Plastic Drum |
Jaw Type | Adjustable Alloy Steel Eagle Claw |
Frame Material | Thickened Q345 Carbon Steel, Anti-rust Spray |
Wheel Options | Nylon Silent Wheel / PU Wheel / Solid Rubber Wheel / Inflatable Wheel |
Overall Dimension | 9208901130mm |
Net Weight | 50kg |
Certification | CE |
Warranty | 1 Year Whole Machine |
